ماڊل نمبر.: RS860EQL-GD40
Size: 86-inches
Brightness: 4000-nits
آمد و رفت: Land,Air,Express,Ocean
پورٽ: Shenzhen
ادائيگي جو قسم: L/C,T/T,D/P,D/A,Paypal
انڪوٽرم: FOB,CFR,CIF,EXW
The file is encrypted. Please fill in the following information to continue accessing it
صنعتي 86CNCH هاء TIN 110C ٻاهرين اسڪرين پينل ايل سي ڊي
| Item | 86.0'' high brightness LCD panel |
| Screen Size | 86 inches |
| Display Area | 1895.04*1065.96mm |
| Outline Dimenssion | 1930*1111*75.5mm |
| Panel Type | High brightness LCD with WLED |
| Configuration | RGBW Vertical Stripe |
| Resolution | 3840(RGB)×2160 , UHD |
| Brightness | 4000nits |
| Aspect Ratio | 16:9 |
| Constrast Ratio | 1200:1 (Typ.) (TM) |
| Response Time | 8ms (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Driver Elements | a-Si TFT-LCD |
| Surface Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Display Color | 16.7M/1.07B |
| Display Mode | IPS, Normally Black, Transmissive |
| Interface Type | 56 pins V-by-One 8 lane , Connector |
| Input Voltage | DC24V |
| Power | 990W |
| Weight | 40kg |
| Backlit Lifetime | 50000hrs |
| Operating Temp. | -20°- 70°C |
| Storage Temp. | -20°- 70°C |
